Specifications
| T Y P E | PC102W | ||||
| Ordering number | 02785 | ||||
| Frequency range | DC+22 kHz, 47-2400 MHz | ||||
| RF through loss | < 1.5 dB | ||||
| Multiswitch powering/control | 14/18 V & 600 mA max. EN50494/EN50607/DiSEqC 2.0 | ||||
| Supply voltage | 18 – 20 V | ||||
| Current consumption | 5 V 200 mA (from USB port) 20 V 50 mA* (from power supply) |
||||
| Operating temperature range | 0° ÷ + 50°C | ||||
| Dimensions/Weight (packed) | 133x73x39 mm/0.36 kg |
* without external DC feeding; power supply included in scope of delivery
